SWIVEL FOOT REINFORCED POLYAMIDE

Swivel Foot Reinforced Polyamide consist of a black base and zinc plated steel threaded stud. Available in 3 base diameter options these swivel feet can withstand static loads of up to 12000 Newtons. Suitable for use on industrial equipment and machinery.

From £5.4010
Colour
Black
Material
Reinforced Polyamide
Insert Material
Steel ZP

If you are designing or developing a new product or wish to test one of our products before purchasing, a free sample service is available for many of our products. Simply fill in the form below.

Customer Details

Product Sample Details

We offer a large range of different style adjustable feet, please consider the below when choosing the correct product. For assistance, please contact our sales department 01282 424376 sales@cotel.co.uk

FOOT TYPE: Fixed (Where the screw is fixed rigid to the base). Articulating (Where the screw rotates on the base). Swivel (Where the screw has a ball joint that fits into the base - ideal for uneven surfaces).

BASE SIZE & TYPE: Diameter (Measure the outside diameter of the foot pad). Height (Ensure your product is raised off the surface at the correct height). Special Options (Bolt-down bases and anti-slip bases are available).

THREAD SIZE: Thread diameter (This is thickness of the thread M6, M8, M10, M12, M16, M20, M24, M30). Thread Length - (Choose what length of thread is suitable for your application).

MATERIALS: Base material (Choose from plastic, rubber, zp steel or stainless steel). Thread material (Choose from zp steel or stainless steel).

Lorem Ipsum is simply dummy text

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged. It was popularised in the 1960s with the release of Letraset sheets containing Lorem Ipsum passages, and more recently with desktop publishing software like Aldus PageMaker including versions of Lorem Ipsum.

Part No. D H d1 Q H1 R E s Max Static Load Newton Min Qty Price Lead Time
4950/40/112 40 17 h_up M8 70 23.5 12.5 13 5 10000 1
£5.4010
In Stock Add To Cart
4950/40/130 40 17 h_up M10 70 23.5 12.5 13 5 10000 1
£5.7040
In Stock Add To Cart
4950/40/163 40 17 h_up M12 100 23.5 12.5 13 5 10000 1
£6.9152
In Stock Add To Cart
4950/50/107 50 18 h_up M8 45 24.5 12.5 13 5 10000 1
£5.4010
In Stock Add To Cart
4950/50/136 50 18 h_up M10 100 24.5 12.5 13 5 10000 1
£6.9152
In Stock Add To Cart
4950/50/163 50 18 h_up M12 100 24.5 12.5 13 5 10000 1
£7.2684
In Stock Add To Cart
4950/60/112 60 20 h_up M8 70 26.5 12.5 13 5 10000 1
£6.8648
In Stock Add To Cart
4950/60/163 60 20 h_up M12 100 26.5 12.5 13 5 10000 1
£7.8740
In Stock Add To Cart
4950/60/224 60 20 h_up M16 110 26.5 12.5 13 5 12000 1
£9.3694
In Stock Add To Cart
reset
Order in multiples of
Download PDF Download PDF
